Base Edges
Base Edges
111-9770: 3405mm Long Steel Edge
Cat® 305mm Width Steel Base Edge with 30 Holes used for Bucket Lines
Cat
End Depth (in)
12.0
Overall Width (in)
134.055
Bevel Angle
22.6
Material
Abrasion Resistant Steel,Boron Steel
Thickness Class
45
Adapter Type
Bolt-on Adapters
Adapter Quantity
8
Shape
Straight
Width Between Sidebars (in)
131.89
149-5437: 1883mm Long Steel Edge
Cat® Steel Edge of 19.10mm Thickness with 21 Holes used for Bucket Work Tools
Cat
Overall Width (in)
74.134
End Depth (in)
6.0
Bevel Angle
22.5
Material
Boron Steel,Abrasion Resistant Steel
Thickness Class
20
Adapter Type
Bolt-on Uniteeth
Adapter Quantity
8
Shape
Straight
Width Between Sidebars (in)
72.256
7I-3015: Weld-on Base Edge
Weld-on Base Edge 40mm
Cat
Overall Width (in)
125.709
End Depth (in)
11.811
Bevel Angle
22.6
Material
Boron Steel,Abrasion Resistant Steel,Alloy Steel
Thickness Class
40
Adapter Type
Bolt-on Adapters
Adapter Quantity
8
Shape
Straight
Width Between Sidebars (in)
123.268
199-7722: 2036mm Long Steel Edge
Cat® Steel Edge of 19.10mm Thickness with 26 Holes used for Bucket Work Tools
Cat
Overall Width (in)
80.157
End Depth (in)
6.0
Bevel Angle
22.5
Material
Boron Steel,Abrasion Resistant Steel
Thickness Class
20
Adapter Type
Bolt-on Adapters
Adapter Quantity
9
Shape
Straight
Width Between Sidebars (in)
78.28
141-4847: 2886mm Long Steel Bucket Base Edge
Shop Cat® part 141-4847 30mm thick steel bucket base edge with 30 hole. This GET part is engineered to provide impact resistance for ground engaging GET bucket tools.
Cat
Overall Width (in)
113.622
End Depth (in)
11.102
Bevel Angle
22.5
Material
Boron Steel,Abrasion Resistant Steel
Thickness Class
32
Adapter Type
Bolt-on Adapters
Adapter Quantity
8
Shape
Straight
Width Between Sidebars (in)
111.969
229-3432: 2188mm Long Steel Edge
Cat® Steel Edge of 19.10mm Thickness with 24 Holes used for Bucket Work Tools
Cat
Overall Width (in)
86.142
End Depth (in)
6.0
Bevel Angle
22.5
Material
Boron Steel,Abrasion Resistant Steel
Thickness Class
20
Adapter Type
Bolt-on Adapters
Adapter Quantity
9
Shape
Straight
Width Between Sidebars (in)
84.264
9R-4672: 2262mm Long Steel Edge
Cat® Steel Edge of 20mm Thickness with 16 Holes used for Bucket Work Tools
Cat
Overall Width (in)
89.055
End Depth (in)
5.906
Bevel Angle
22.6
Material
Abrasion Resistant Steel,Boron Steel
Thickness Class
20
Adapter Type
Bolt-on Adapters
Adapter Quantity
8
Shape
Straight
Width Between Sidebars (in)
87.087
4E-0659: 2524mm Long Steel Edge
Cat® Steel Edge of 25mm Thickness with 30 Holes used for Bucket Work Tools
Cat
Overall Length (in)
99.4
Overall Width (in)
99.37
Overall Height (in)
1.0
Weight (lb)
240.1
Material
Steel,Boron Steel,Abrasion Resistant Steel
End Depth (in)
9.646
Bevel Angle
22.6
Thickness Class
25
Adapter Type
Bolt-on Adapters
Adapter Quantity
8
Shape
Straight
Width Between Sidebars (in)
98.425
108-1066: 60mm Thick Edge
Straight (60 mm T x 1954 mm W x 380 mm D)
Cat
End Depth (in)
14.961
Overall Width (in)
76.929
Bevel Angle
22.5
Material
Structural Steel,Boron Steel,Alloy Steel
Thickness Class
60
Cut to Length
Cut-to-length
Adapter Type
Weld-on Adapters
Shape
Straight
Width Between Sidebars (in)
71.024
149-5436: 1730mm Long Steel Edge
Cat® Steel Edge of 19.10mm Thickness used for Bucket Work Tools
Cat
Overall Width (in)
68.11
End Depth (in)
6.0
Bevel Angle
22.5
Material
Boron Steel,Abrasion Resistant Steel
Thickness Class
20
Adapter Type
Bolt-on Adapters
Adapter Quantity
8
Shape
Straight
Width Between Sidebars (in)
66.232
110-4712: 2723mm Long Steel Edge
Cat® 245mm Width Steel Base Edge with 28 Holes used for Bucket Lines
Cat
End Depth (in)
9.646
Overall Width (in)
107.205
Bevel Angle
22.6
Material
Boron Steel,Abrasion Resistant Steel
Thickness Class
25
Adapter Type
Bolt-on Adapters
Adapter Quantity
8
Shape
Straight
Width Between Sidebars (in)
106.102
6I-5303: 1999mm Long Cutting Edge
Cat® 1999mm Long Bucket Cutting Steel Edge used in Excavators
Cat
Overall Width (in)
78.701
End Depth (in)
14.961
Bevel Angle
22.5
Material
Structural Steel,Boron Steel,Carbon Steel,Alloy Steel
Thickness Class
70
Cut to Length
Cut-to-length
Adapter Type
Weld-on Adapters
Shape
Straight
Width Between Sidebars (in)
71.811
9R-5313: 2406mm Long Steel Edge
Cat® 150mm Width Steel Base Edge with 15 Holes used for Bucket Lines
Cat
End Depth (in)
5.906
Overall Width (in)
94.724
Bevel Angle
22.6
Material
Boron Steel,Abrasion Resistant Steel
Thickness Class
20
Adapter Type
Bolt-on Adapters
Adapter Quantity
8
Shape
Straight
Width Between Sidebars (in)
92.756
578-9633: Bucket Base Edge
Cat® 50 mm x 2600 mm Spade Base Edge
Cat
Shape
Spade
Overall Width (in)
102.362
End Depth (in)
15.287
Bevel Angle
0.0
Material
Abrasion Resistant Steel,Alloy Steel
Thickness Class
50
Width Between Sidebars (in)
97.441
119-3174: 80mm Thick Bucket Cutting Edge
Cat® Bucket Cutting Edge efficiently penetrates and cuts through different materials during excavation, ensuring an effective cutting operation
Cat
Cut to Length
Cut-to-length
Overall Width (in)
93.031
End Depth (in)
19.685
Bevel Angle
22.5
Material
Structural Steel,Boron Steel,Alloy Steel
Thickness Class
80
Adapter Type
Weld-on Adapters
Shape
Straight
Width Between Sidebars (in)
85.157
4E-6085: 44.5mm Thick Bucket Cutting Edge
Cat® Bucket Cutting Edge efficiently penetrates and cuts through different materials during excavation, ensuring an effective cutting operation
Cat
Overall Width (in)
140.157
End Depth (in)
12.008
Bevel Angle
22.0
Material
Abrasion Resistant Steel,Boron Steel
Thickness Class
45
Adapter Type
Bolt-on Adapters
Adapter Quantity
8
Shape
Straight
Width Between Sidebars (in)
135.78
