643-2399: Sprocket
CatĀ® Sprocket 86mm Track Pitch, 15 Teeth
Cat
Roll Path Diameter (in)
0
Tip Radius (in)
8.346
Track Pitch (in)
3.386
UC System
HD,HD
Sprocket Pitch Diameter (in)
16.276
Tooth Width (in)
1.811
Number of Teeth
15
Sprocket Pitch (in)
3.386
110-2664: 902mm Outer Diameter Sprocket Hub
CatĀ® 902mm Outer Diameter Sprocket Ductile Iron Hub used in Final Drive
Cat
Material
Ductile (Spheroidal) Iron
104-3140: Final Drive Sprocket Hub
CatĀ® Final Drive Sprocket Hub connects the sprocket to the final drive output shaft, transfers drive torque while maintaining aligned sprocket rotation.
Cat
Material
Ductile (Spheroidal) Iron
621-4237: Sprocket Housing
CatĀ® Sprocket Housing used in Final Drive
Cat
Material
Ductile Iron Casting,Ductile (Spheroidal) Iron
Outer Diameter (in)
26.55
Weight (lb)
324.96
Width (in)
12.77
636-5721: 25 Teeth Sound Suppression Sprocket Segment
CatĀ® Track Segment Tough Steel, 6 Bolts, 5 Teeth, 260.35mm Track Pitch
Cat
Number of Teeth
5
Material
Alloy Steel,Sound Pressure Level Alloy
Number of Bolts
6
Tip Radius (in)
20.827
Pitch Circle Radius (in)
20.608
Bushing Radius (in)
1.87
UC System
HD,HD
Relieved
Yes
Tooth Width (in)
4.528
Packing Offset Radius (in)
20.507
Material Type
Tough Steel
Bolt Circle Radius (in)
16.535
Pitch (in)
10.25
Back Lash (in)
0.315
Sound Segment
Yes
Sprocket Mounting Type
Offset
UC System - Designed For
Heavy Duty
Pocket Angle (degrees)
30
Bolt Thread Size
1
Inner Radius (in)
15.197
278-3322: Final Drive Sprocket
CatĀ® Final Drive Sprocket engages with the final drive components to transmit torque, ensures reliable power delivery, and maintains drive efficiency
Cat
Number of Sprocket Teeth
21.0
Number of Sprocket Segments
1.0
Outside Diameter (in)
12.66
Inside Diameter (in)
3.17
Overall Length (in)
1.93
276-4450: 22 Tooth Sprocket
CatĀ® 22 Tooth Drive Sprocket for Landscape Rake
Cat
Inside Diameter (in)
1.75
Material
Steel,Carbon Steel
Number of Sprocket Teeth
22.0
Width (in)
1.6
512-2438: Rear Axle Final Drive Shaft Sprocket
CatĀ® Rear Axle Final Drive Shaft Sprocket transfers torque from the final drive shaft to the axle hub, enabling smooth and efficient wheel rotation
Cat
Weight (lb)
39.02
179-6323: Sprocket
CatĀ® Sprocket (Drive) (Trencher)
Cat
Number of Sprocket Teeth
15.0
Outside Diameter (in)
10.61
Inside Diameter (in)
2.031
Material
Carbon Steel,Alloy Zinc
276-4449: Power Drive Sprocket
CatĀ® 100mm Diameter Power Drive Sprocket With 22-Teeth
Cat
Height (in)
3.94
Length (in)
1.97
Material
Steel,Carbon Steel
Weight (lb)
0.01
643-2435: Power Train Drive Sprocket
CatĀ® Sprocket 86mm Track Pitch, 16 Teeth
Cat
Roll Path Diameter (in)
0
Tip Radius (in)
9.843
Track Pitch (in)
3.386
UC System
GD,GD
Sprocket Pitch Diameter (in)
8.642
Tooth Width (in)
1.811
Number of Teeth
16
Sprocket Pitch (in)
3.386
587-0815: 23 Teeth Axle Sprocket
CatĀ® 32 Tooth Axle Sprocket for Skid Steer Loader Tandem Drive System
Cat
Number of Sprocket Teeth
32.0
Outside Diameter (in)
10.8
Width (in)
2.2
643-0177: 12 Teeth Screed Chain Sprocket
CatĀ® Screed Chain Sprocket transmits rotational motion to the screed chain, facilitating smooth and accurate adjustment of the screed width during operations
Cat
Outer Diameter (in)
2.17
Inner Diameter (in)
1.0
Width (in)
0.87
Number of Sprocket Teeth
12.0
Thread
1/4"-20-2B
Weight (lb)
0.31
Material
Coating Mixed: Nonmetallic,Carbon Steel
