Parts diagram for 099-0173
View Detailed Parts Diagrams
Add Your Equipment
Description for part number 099-0173
Description: Backup rings prevent seal extrusion in high pressure applications and help protect the life of overall sealing system from pressure surges.
Attributes: Cat® backup rings are designed in conjunction with the elastomeric seal and mating components to contribute significantly to the life and performance of the sealing system in high pressure applications. They may be solid or split depending on the application requirements.
Backup ring dimensions are consistently held to tight tolerances to ensure they properly bridge the seal groove and the mating surface. Materials are selected for their pressure and abrasion resistance.
Cat® sealing system uses a robust design, testing, and validation process. Buy the latest Genuine Cat® seal to protect your investment.
Applications: Backup rings are used in high pressure static and dynamic sealing applications, such as hydraulic pumps, valves and engine systems.
View More
Warning:This product can expose you to chemicals including Tetrafluoroethylene, which is known to the State of California to cause cancer, and Perfluorooctanoic acid (PFOA), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
Material Description: PTFE provides superior performance in Air, Engine Oil, Diesel Fuel and Coolant applications, but is sensitive to installation damage and debris. It works well at very high temperatures.
Cross Section Width (in): 0.05
Notes: Dimensions and Material Descriptions provided for reference only. Color may differ from image.
Cross Section Height (mm): 3
Cross Section Width (mm): 1.2
Seal/O-Ring Type: Split
Cross Section Height (in): 0.12
Radial Thickness (mm): 3
View More
Compatible Models for part number 099-0173
MINI HYD EXCAVATOR
307-A
EXCAVATOR
307-A 312C L 307 312-A 312C 313D2
View More
