Cat® XN Spiral Permanent Coupling CAT FLANGE - Straight

Brand: Cat

Product Images

496-2307: Permanent Coupling

Cat® XN Spiral Permanent Coupling CAT FLANGE - Straight

Brand: Cat

Will it fit or looking for a repair?Add your equipment to see if this part fits or if there are repair options available.

Check Price

Warranty Information

Return Policy

Description

Cat Spiral permanent couplings exceed SAE/ISO requirements for the best in reliable hose and coupling performance

Warning:This product can expose you to chemicals including Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.

Cat® Hose Assembly Products Warning

Improper selections of hose and coupling combinations will void warranties and may result in serious personal injury or death, property damage, or component and machine system failure. Cat® hose assembly products are designed and tested as a system to achieve a reliable connection, thus maximizing hydraulic system safety and dependability. It is also recommended that appropriate and properly maintained Caterpillar tooling is used to ensure hoses are crimped to specifications. Use of Caterpillar hose with other manufacturer’s couplings or the use of Caterpillar couplings with other manufacturer’s hose may result in the production of unreliable, unsafe or under-performing hose assemblies. It is not recommended or authorized by Caterpillar. For additional information see SAE J1273 section 6.3 and ISO 17165-2 section 6.3.

Cat® Hose Assembly Products Warning

Improper selections of hose and coupling combinations will void warranties and may result in serious personal injury or death, property damage, or component and machine system failure.

Specifications

Connector:

Permanent

Material:

STEEL,Alloy Zinc

Coating:

Zinc Plated

Shape:

Straight

Connector Type:

-16 CAT FLANGE

Length (mm):

155

Length (in):

6.1

Cut-Off Factor (mm):

Cut-Off Factor (in):

3.35

Recommended Hose Size (mm):

25.4

Recommended Hose Size (in):

Compatible With:

SAE 100R12, SAE 100R13, SAE 100R15

Seal Type:

NBR 1P-3703, FKM 235-2474

Description:

Permanent Coupling 16XN

Applications:

Permanent Coupling for use with hydraulic hose. For additional information contact your CAT local dealer

Compatible Models

We currently do not have compatibility information for this part.
