Irregular Plates
Irregular Plates
601-5779: Equalizer Bar Steel Guard
Guard (End Pins)
Cat
Material
Steel,Alloy Zinc,Structural Steel
Overall Length (in)
3.45
Overall Width (in)
1.77
Overall Height (in)
1.94
7T-4213: Track Adjuster Stop
Cat® Track Adjuster and Recoil Stop to control the tension of the track and prevent excessive recoil movement
Cat
Material
Steel,Structural Steel
Overall Length (in)
6.299
Overall Width (in)
2.008
Thickness (in)
0.472
Hole Size (in)
0.807
Fits Bolt Sizes (in)
3/4-10
7G-2421: Track Adjuster Stop
Cat® Track Adjuster and Recoil Stop to control the tension of the track and prevent excessive recoil movement
Cat
Material
Steel,Structural Steel
Overall Length (in)
8.268
Overall Width (in)
2.668
Thickness (in)
0.787
Hole Size (in)
0.807
Fits Bolt Sizes (in)
3/4-10
203-9383: 6mm Thick Guard Support Plate
Cat® 6mm Thick Guard Support Steel Plate used in Pivot Shaft Retainer
Cat
Material
Steel,Carbon Steel
Finish
Paint
Color
Cat Yellow,Cat Yellow
Overall Length (in)
11.66
Overall Width (in)
3.23
Thickness (in)
0.24
Hole Size (in)
0.54 (3X)
285-3692: 45.50mm Overall Length Spacer
Cat® 2 Holes of 8mm Diameter Adhesive Spacer used for Additional Stretch in Cab Doors
Cat
Overall Width (in)
1.791
Overall Length (in)
1.161
Length (in)
0.078
9G-0611: Track Adjuster Stop
Cat® Track Adjuster and Recoil Stop to control the tension of the track and prevent excessive recoil movement
Cat
Material
Steel,Structural Steel
Overall Length (in)
7.402
Overall Width (in)
2.181
Thickness (in)
0.787
Hole Size (in)
0.807
Fits Bolt Sizes (in)
3/4-10
3K-0196: Steel Dirt Guard
Cat® Steel Dirt Guard for Yoke Component
Cat
Material Description
STEEL
Outer Diameter (in)
4.5
Overall Width (in)
0.75
Weight (lb)
0.37
Material
Carbon Steel
110-5334: 3mm Thick Spacer
Cat® 3mm Thick Right Hand Side Spacer to extend the length of the blade, providing increased reach and versatility for earthmoving and leveling tasks
Cat
Width (in)
0.46
Thickness (in)
0.118
Material
STEEL,Carbon Steel
Length (in)
23.748
Hole Size (in)
0.807
6T-9127: Track Adjuster Stop
Cat® Track Adjuster and Recoil Stop to control the tension of the track and prevent excessive recoil movement
Cat
Material
Steel,Structural Steel
Overall Length (in)
9.134
Overall Width (in)
3.124
Thickness (in)
0.984
Hole Size (in)
0.984
Fits Bolt Sizes (in)
7/8-9
178-8858: 2mm Thick Scraper Blade
Cat® Steel Blade Scraper used for Reduces Accumulation of Debris in Paving Compactor.
Cat
Material
Steel,Carbon Steel
Length (in)
8.25
Width (in)
4.12
Thickness (in)
0.08
145-3035: 28mm Thick Mounting Plate
Cat® 28mm Thick Mounting Plate for Track Adjuster and Recoil Spring
Cat
Material
Steel,Structural Steel,Carbon Steel
Length (in)
9.45
Thickness (in)
1.1
339-1884: Left Hand Side Equalizer Bar Guard
LH Guard (Equalizer Bar)
Cat
Material
Steel,Structural Steel
Overall Length (in)
12.23
Overall Width (in)
9.07
Overall Height (in)
3.15
508-9726: Bottom Guard Sheet
Cat® Steel Bottom Guard Sheet (Plate), L X W: 851 X 579mm
Cat
Hole Size (in)
0.61 (4X)
Length (in)
33.5
Material
Steel,Carbon Steel
Material Thickness (in)
0.08
Standard Color
Cat Yellow
Width (in)
22.8
310-7376: 9mm Thick Track Guide Plate
Cat® 9mm Thick Steel Track Guide Plate Used In Undercarriage
Cat
Length (in)
7.83
Thickness (in)
0.36
Material
Steel-Carbon,Steel,Carbon Steel
Height (in)
5.28
Weight (lb)
1.61
Approx. Weight (lb)
3.44
Width (in)
5.0
339-1883: 10mm Thick Multiple Bend Steel Guard
RH Guard (Equalizer Bar)
Cat
Material
Steel,Structural Steel
Overall Length (in)
12.23
Overall Width (in)
9.07
Overall Height (in)
3.15
512-3589: 3mm Thick Clamp Body Cover Plate
Cat® 3mm Thick Clamp Body Steel Cover Plate used in Hydrostatic Lines
Cat
Overall Length (in)
5.38
Overall Width (in)
4.7
Material Thickness (in)
0.12
Weight (lb)
0.61
Material
Steel,Carbon Steel
